These knuckles are manufactured by Reid Racing (Dedenbear) as heavy duty components for building a Ford style Dana 44 axle. They directly accept Ford style spindles and related outer components.
These knuckles feature:
- Cast from high strength ductile iron
- Beefed up with extra material and ribbing
- Flat tops machined and drilled for high steer arms
- 4th bolt hole for high steer arms increases clamping force and sheer strength
- 3 bolt high steer arms still fit
- 3/8″ thickness added to flat top of the knuckle for high steer tie rod to leaf spring clearance
- Cast-in DUAL steering stops eliminate bent stop bolts that can cause u-joint and axle failures
- Tapered tie rod holes accept factory tie rod ends
- Tie rod holes can be drilled to accept 3/4″ heim ends
- Powder coated bright orange for long lasting looks
- Interchangeable with all factory and aftermarket Dana 44 components
- Fully machined and ready for installation
- Tie rod hole is tapered from the bottom to the top
- Based on the Bronco disc brake knuckle and fit 1/2 and 3/4 ton brakes
- The only aftermarket knuckle available for a Ford Dana 44.
This item is a pair of knuckles.
